Classic British Rock Sound in a Compact Format
The NUX NDS-2 Brownie is a compact distortion pedal inspired by the powerful British amplifier tones of the seventies. The pedal delivers full distortion with warm overtones, smooth sustain, and a tight low end.
From classic hard rock and heavy crunch to a saturated lead sound, the Brownie offers ample gain for powerful riffs and expressive solos, without the sound becoming unnecessarily muddy.
Tube-like Character and Tight Bass Response
The specially designed BJT input stage emulates the overdrive of a preamp tube. An asymmetrical clipping circuit adds an organic character, while low frequencies are processed in a controlled manner. This ensures that chords and fast riffs remain clearly audible even at higher gain settings.
The output stage uses a low-noise operational amplifier and red LEDs for smooth, symmetrical clipping. The result is a robust yet musical distortion with a recognizable vintage rock sound.
Simple Operation with Three Controls
Gain controls the amount of distortion, from a heavy crunch to a saturated high-gain sound. The Tone knob changes the brightness of the sound, while Level sets the overall output volume.
Thanks to its clear controls, the NUX Brownie can be quickly adjusted for different guitars, amplifiers, and playing styles.
True Bypass and Compact Design
The true-bypass footswitch allows the original signal to pass directly through when the effect is off. The sturdy, compact housing takes up little space on your pedalboard and is suitable for rehearsals, recordings, and performances.
The Brownie is powered by a standard 9V DC adapter with a center-negative polarity. A power adapter is not included as standard.
Main Features
- Compact distortion pedal for electric guitar
- Inspired by British rock sounds from the seventies
- From heavy crunch to saturated distortion
- BJT input stage with tube-like overdrive character
- Asymmetrical clipping for an organic sound
- Tight and controlled bass response
- Controls for Gain, Tone, and Level
- True-bypass switching
- Compact metal housing
Specifications
| Effect Type | Distortion |
|---|---|
| Controls | Gain, Tone, and Level |
| Bypass | True bypass |
| Input | 6.3 mm mono-jack |
| Output | 6.3 mm mono-jack |
| Input Impedance | 470 kΩ |
| Output Impedance | 100 Ω |
| Power Supply | 9V DC, center-negative, minimum 100 mA |
| Power Adapter Included | No |
| Dimensions | 94 × 51 × 53 mm |
| Weight | 174 grams |
| Model | NDS-2 |
|---|---|
| Serie | Mini Core Series |
| Land van herkomst | China |
| Instrument | Effectpedaal |
| Instrument familie | Elektrische gitaar |
| Gewicht | 174 grams |
| Afmetingen | 94 x 51 x 53 mm |
| Artikelnummer | NDS-2 |
